A6-M-6S
MOTOR
6S FOC 50A
ESC
MF2311P-M
PROPELLER
A6-M-6S
MOTOR
6S FOC 50A
ESC
MF2311P-M
PROPELLER
A6-M-6S RECOMMENDATIONS
Take-off weight
8~10kg
Quadcopter
Take-off weight
12~15kg
Hexacopter
Take-off weight
8~10kg
Quadcopter
Take-off weight
12~15kg
Hexacopter
| Model No. | A6-M KV160 | Tube size | 25mm |
| Setup | A6-M (Motor)+12S FOC 50A (ESC)+ MF2311P-M (Prop) | Wire material, wire gauge, color | Power wires: 16#AWG red & black Signal wires: 5P Teflon |
| Recommended battery | 12S (LiPo) | Wire length | 600±5mm |
| Rated thrust | 2~2.5kg | Weight | 380g±2%(incl. Wires+prop) |
| Efficiency at rated thrust | 9.1g/W (2.5kg) | IP | IPX6 |
| Max. thrust | 7.5kg | Recommended ambient temperature | -20℃～50℃ |
| Motor specs. | |||
| Stator size | 60*9mm | KV | 160 |
| ESC specs. | |||
| Throttle range | 1050~1950us (fixed) | Max. voltage | 61V |
| Protocol | DRONE CAN、 UAV CAN、 CUBE CAN | Peak current (for a short time) | 40A (Openenvironment andtemperature≤60℃) |
| Control method | PWM/CAN | BEC | NO |
| Prop specs | |||
| Model No. | MF2311P-M (Polymer Folding) | Length | 23 inch(585mm) |
| Type | Voltage (V) | Throttle (%) | Current (A) | Thrust (g) | Motor efficiency (%) | Overall efficiency (gf/W) | Operating temperature (℃) | |
| A6-M KV160 + 14S FOC 50A + MF2311P-M | 50.98 | 30 | 0.87 | 677 | 73.1 | 15.2 | 122 (Ambient temperature: 32) | |
| 50.97 | 35 | 1.63 | 1084 | 77.4 | 13.1 | |||
| 50.95 | 40 | 2.71 | 1564 | 79.1 | 11.3 | |||
| 50.93 | 45 | 4.14 | 2110 | 79.6 | 10.0 | |||
| 50.91 | 50 | 6.01 | 2719 | 79.6 | 8.9 | |||
| 50.87 | 55 | 8.21 | 3356 | 79.0 | 8.0 | |||
| 50.84 | 60 | 10.84 | 4020 | 78.3 | 7.3 | |||
| 50.79 | 65 | 13.80 | 4694 | 77.3 | 6.7 | |||
| 50.75 | 70 | 16.97 | 5341 | 76.2 | 6.2 | |||
| 50.70 | 75 | 20.33 | 5946 | 75.1 | 5.8 | |||
| 50.65 | 80 | 23.75 | 6487 | 73.3 | 5.4 | |||
| 50.61 | 85 | 27.05 | 6961 | 71.7 | 5.1 | |||
| 50.56 | 90 | 30.57 | 7422 | 69.8 | 4.8 | |||
| 50.53 | 95 | 32.04 | 7592 | 68.9 | 4.7 | |||
| 50.53 | 100 | 32.02 | 7550 | 68.3 | 4.7 | |||
Note: Temperature in the chart is the stator temperature after running @80% throttle for 3mins. (Data above based on benchtest at LIGPOWER lab are for reference only.) | ||||||||
| A6-M KV160 + 14S FOC 50A + MF2311P-M | 44.00 | 30 | 0.66 | 499 | 73.2 | 17.1 | 106 (Ambient temperature: 32) | |
| 43.99 | 35 | 1.28 | 824 | 76.8 | 14.6 | |||
| 43.97 | 40 | 2.13 | 1192 | 78.5 | 12.7 | |||
| 43.96 | 45 | 3.26 | 1616 | 79.4 | 11.3 | |||
| 43.94 | 50 | 4.75 | 2112 | 80.2 | 10.1 | |||
| 43.91 | 55 | 6.50 | 2588 | 79.5 | 9.1 | |||
| 43.88 | 60 | 8.59 | 3131 | 78.9 | 8.3 | |||
| 43.85 | 65 | 11.04 | 3684 | 78.3 | 7.6 | |||
| 43.81 | 70 | 13.74 | 4235 | 77.2 | 7.0 | |||
| 43.76 | 75 | 16.74 | 4805 | 76.5 | 6.6 | |||
| 43.72 | 80 | 19.95 | 5356 | 75.7 | 6.1 | |||
| 43.67 | 85 | 23.10 | 5830 | 74.8 | 5.8 | |||
| 43.63 | 90 | 26.33 | 6304 | 73.5 | 5.5 | |||
| 43.61 | 95 | 27.56 | 6485 | 73.0 | 5.4 | |||
| 43.61 | 100 | 27.51 | 6458 | 72.6 | 5.4 | |||
Note: Temperature in the chart is the stator temperature after running @80% throttle for 3mins. (Data above based on benchtest at LIGPOWER lab are for reference only.) | ||||||||
